1, Kev ua haujlwm ntawm kev pib relay
Muaj ntau yam khoom siv tshuab ua lub luag haujlwm rau kev tswj cov khoom siv tsheb. Hauv qab no, peb yuav tsom mus rau qhov pib relay. Lub luag haujlwm tseem ceeb ntawm lub oob khab relay yog muab qhov yuav tsum tau muaj high voltage thiab tam sim no rau lub oob khab, yog li smoothly pib lub cav. Tus pib relays nyob rau hauv kev ua lag luam feem ntau yog muab faib ua ob hom: ncaj qha thiab tsis ncaj. Kuj tseem muaj ob txoj hauv kev txuas txuas rau nws. Lub direct relay ncaj qha txuas cov kab hluav taws xob mus rau lub oob khab, thaum lub indirect relay thawj zaug txuas lub hwj chim kab mus rau lub relay thiab ces outputs tam sim no los ntawm lub relay mus rau lub oob khab.
2, Cov txheej txheem ntawm kev pib relay
Direct starter relay thaiv kab
Cov txheej txheem xaim ntawm lub tshuab hluav taws xob ncaj qha relay yog qhov yooj yim vim nws txuas ncaj qha rau lub tshuab hluav taws xob. Cov kauj ruam tshwj xeeb yog raws li nram no:
Txuas tus ncej zoo ntawm lub hwj huam mov mus rau tus ncej zoo ntawm lub tshuab hluav taws xob pib. Hauv cov tsheb qub, qhov no feem ntau txhais tau hais tias txuas tus ncej zoo ntawm lub zog hluav taws xob mus rau hluav taws xob hluav taws xob ntawm qhov pib.
Txuas lub davhlau ya nyob twg tsis zoo ntawm lub hwj huam mov mus rau lub rectifier los yog lub cav lub cev ntawm lub cav.
Xyuas kom meej tias cov av xaim ntawm lub oob khab txuas nrog lub hauv paus system ntawm lub tsheb lub cev.
Indirect starter relay thaiv
Kev xaim ntawm indirect starter relay yog qhov nyuaj me ntsis. Daim duab kab hluav taws xob ntawm 12v pib relay yog raws li hauv qab no:
Txuas lub hwj chim qaum mus rau "B davhlau ya nyob twg" (tseem hu ua "30 davhlau ya nyob twg") ntawm lub relay.
Txuas lub 'S davhlau ya nyob twg' mus rau 'pib teeb liab' tso zis davhlau ya nyob twg ntawm lub ignition hloov.
Txuas lub "M davhlau ya nyob twg" (tseem hu ua "87 davhlau ya nyob twg") ntawm lub relay mus rau "S davhlau ya nyob twg" ntawm lub starter.
Txuas lub "E davhlau ya nyob twg" (tseem hu ua "87a davhlau ya nyob twg") ntawm lub relay mus rau "M davhlau ya nyob twg" ntawm lub starter.
Xyuas kom meej tias "G davhlau ya nyob twg" ntawm lub relay txuas nrog lub hauv paus system ntawm lub tsheb lub cev.
3, Kev ceev faj
Thaum xaim qhov pib relay, cov ntsiab lus hauv qab no yuav tsum raug sau tseg:
Ua raws li cov kab hluav taws xob kom raug nyob rau hauv phau ntawv qhia kom tsis txhob muaj kev puas tsuaj rau lub tsheb hluav taws xob lossis txawm tias pib tsis ua haujlwm los ntawm txoj kev xaim tsis raug.
Ua ntej ua txhua yam kev ua haujlwm, xyuas kom lub hwj chim raug tua kom tshem tawm qhov kev pheej hmoo ntawm hluav taws xob poob siab.
Thaum kawg, nws yog ib qho tsim nyog los xaiv thiab siv cov relays uas ua tau raws li cov lus qhia tshwj xeeb kom ntseeg tau tias lub tshuab hluav taws xob tuaj yeem ua haujlwm tau zoo. Yog tias siv cov khoom siv tsis zoo lossis tsis sib xws, nws yuav cuam tshuam rau kev nyab xeeb ntawm cov khoom siv. QIANJIyog ib lub chaw muab khoom zoopib relaysuas tuaj yeem muab cov kev daws teeb meem zoo rau koj.
